ETL (Extract, Transform, Load)

• ETL processes are commonly used to move data from OLTP systems into OLAP systems
• It's a system that extracts the unstructured data from the production databases, transforms the data into structure and meaningful data and loads the data into an analytical environment
• For example, transactional data from an OLTP database could be extracted and aggregated into a data warehouse for analytical processing

Extract

• Collects data from the transactional environment (OLTP)
• Get the raw data (e.g., database log files) and store it in a data lake (e.g., S3 with avro files)

• Volume: TB ~ PB /day
• Variety: mixed data types from multiple sources
• Velocity: high rate

Transform

• Processes the collected raw data from the data lake and outputs data that can be used for analyses
• The raw data is converted into materialized views of datasets
• These datasets have contracts or schemas to help on the data analysis
• The raw data is divided into small batches of subtasks, and then processes each batch separately

Load

• Loads the data into analytical environments or other environment
• Data Warehouse (Google Big Query)
• Databricks

• Back to the transactional environment. E.g., (fraud data)

• Propagates the computed data to BI tools analytical environments (such as Looker, Google Data Studio) and to the production environment

• All the data that was transformed and stored can be accessed through various BI tools

• Data Governance

• Implementing granular access control of data in the analytical environments
• Managing PII data inventory and data subject rights
